# C/C++ Programming  --- ```mermaid kanban column1[STL containers] task1[std::array] task2[std::unordered_map] task3[std::span] column2[Errors] task4[Compile-time, link-time, run-time] task5[Exceptions] task6[Avoiding and finding errors] ``` --- ## More stl containers --- * `std::vector` * `std::array` * `std::unordered_map` --- ### std::array --- * std::vector for dynamic number of elements * std::array for static number of elements Note: * Know the number of elements at compile-time? std::array * Don't know the number of elements at compile-time? std::vector --- ```c++ std::array<int, 5> my_array{1, 2, 3, 4, 5}; ``` Note: * Type and length can be deduced: std::array my_array{1, 2, 3, 4, 5}; * Don't use c-style arrays in c++! int my_array[] = {1, 2, 3, 4, 5}; // bad --- ```c++ my_array[3] = 7; ``` ```c++ for (auto const& value : my_array) { std::println("{}", value); } ``` ```c++ for (auto&& value : my_array) { value += 5; } ``` Note: * Can be used the same way as std::vector --- #### Arrays as function arguments --- ```c++ void read_array(std::array<int, 5> array) { // this function only accepts arrays with 5 elements 🙁 // array is passed by value, so I can't modify items 🙁 } ``` Note: * Passed by value means a copy is made that is used in the function. * Making changes to the copy does not affect the original. --- #### std::span --- A span is an array slice. Note: * It points to a position in the array (by default the start). * And has a number of items (by default the total number of items in the array). --- It is not a copy, but refers it to the original! Note: * Modifying elements through a span will also update the original. --- ```c++ [] using std; int main() { std::span<int> my_span{}; { std::array my_array{1, 2, 3, 4, 5}; my_span = std::span{my_array}; } my_span[0] = 3; // ouch, access violation! 😬 } ``` You are responsible to make sure the lifetime of the array to which it refers is long enough! --- Use std::span to pass arrays to functions. --- ```c++ void modify_array(std::span<int> array) { for (auto&& value : array) { value += 5; } } ``` A span can be used to modify the elements in the original array. Note: * std::span CANNOT be used to add/remove elements! --- ```c++ void read_array(std::span<int const> array) { for (auto const& value : array) { std::print("{},", value); } } ``` Add const to the element type if you don't want to modify the original array. --- ```c++ std::array my_array{1, 2, 3, 4, 5}; std::vector my_vector{1, 2, 3, 4, 5}; int my_c_array[] = {1, 2, 3, 4, 5}; // don't do this in c++ ``` ```c++ read_array(my_array); read_array(my_vector); read_array(my_c_array); ``` ```c++ modify_array(my_array); modify_array(my_vector); modify_array(my_c_array); ``` Note: * Why use span over array? * No template argument for number of elements required * Accepts all sorts of array types (std::array, std::vector, c array, ...) --- #### Best practices --- * Use std::array when you know the number of elements at compile time. * Use std::vector when you don't. --- * Use std::span to pass arrays to functions. * Add const to the element type for read-only access. --- ### std::unordered_map --- std::unordered_map is an associative container that contains key-value pairs with unique keys. --- * std::unordered_map - hashmap * std::map - sorted by key Note: * std::map is a red-black tree * std::map: search, insert, delete all O(log n) (performance depends on the number of elements) * std::unordered_map: search, insert, delete all O(1) (constant time: does not depend on the number of elements) --- ```c++ std::unordered_map<std::string, std::string> colors{ {"red", "#FF0000"}, {"green", "#00FF00"}, {"blue", "#0000FF"} }; ``` Note: * Two template arguments * Key type * Value type --- ```c++ colors["black"] = "#000000"; colors["white"] = "#FFFFFF"; ``` ```c++ // operator[] creates new entry if it does not exist ``` --- ```c++ if (colors.contains("black")) { std::println("black has value {}", colors["black"]); } ``` Note: * Use contains() to avoid accidentally creating default-initialized elements. --- ```c++ // read for (auto const& [color, code] : colors) { std::println("{} = {}", color, code); } ``` ```c++ // modify for (auto&& [color, code] : colors) { code = "[" + code + "]"; } ``` structured bindings Note: * Each iteration we get a key and a value. * Syntax to extract them is [key, value]. * This is called structured bindings. --- * std::string * std::vector * std::array * std::span * std::unordered_map Note: * Our STL journey so far. --- ## Errors --- <div style="display: flex; align-items: center; justify-content: space-around;"> <div style="max-width: 55%;"> > I realized that from now on a large part of my life would be spent finding and correcting my own mistakes. Maurice Wilkes, 1945 </div> <div style="max-width: 45%;">  </div> </div> --- Errors are simply unavoidable when you develop a program, yet the final program must be *free of errors\**. Note: * At least, free of critical errors. --- ### Error classifications --- #### Compile-time errors Errors found by the compiler. Can be further classified based on which language rule is violated. Note: * Syntax errors (for example missing braces, missing ;) * Type errors (for example wrong number of function arguments, incorrect type of function arguments) --- #### Link-time errors Errors found by the linker when it is trying to combine object-files into an executable. Note: * Undefined references (for example function definition is not found) --- #### Run-time errors Errors found by checks in a running program. aka Logic Errors Note: * Errors detected by the computer (OS or hardware, for example access violations, out of memory) * Errors detected by a library (for example bounds checking in the stl) * Errors detected by user code (for example unit tests) --- C++ provides a mechanism to deal with errors. --- ### Exceptions --- Separates the detection and handling of an error. Note: * Detection should be done in the called function * Handling should be done in the calling function --- Ensures that a detected error cannot be ignored. --- #### What if a function detects an error it cannot handle? --- It should not return normally. --- Instead it should throw an exception and pass the responsibility to handle the error to the caller. --- ```c++ int main() try { std::vector vec{1, 2, 3, 4, 5}; vec.at(5) = 6; // out of bounds access } catch (std::exception const& e) { std::cerr << "Exception caught: " << e.what() << '\n'; } ``` ```text Exception caught: vector ``` Note: * Bounds checking at at() function, exception is thrown --- ```c++ int main() try { std::vector vec{1, 2, 3, 4, 5}; vec[5] = 6; // out of bounds access } catch (std::exception const& e) { // no exception thrown, application terminates std::cerr << e.what() << '\n'; } ``` ```text /usr/lib/llvm-19/bin/../include/c++/v1/vector:1436: assertion __n < size() failed: vector[] index out of bounds Aborted (core dumped) ``` Note: * STL only does bounds checking in at() function, not in operator[] * We have enabled STL hardening mode to also check in operator[], this will cause an assertion error and abort instead of exception --- ```c++ struct BadArea : std::exception {}; ``` ```c++ int calculate_area(int length, int width) { if ((length < 0) || (width < 0)) { throw BadArea{}; } return length * width; } ``` ```c++ int main() try { calculate_area(5, -1); } catch (BadArea const& e) { std::cerr << "Bad area exception!\n"; } ``` Note: * Custom exceptions * Best practice: inherit from std::exception --- #### When to use exceptions? --- #### Use exceptions for exceptional cases Invalid user input or failing to open a file is expected and should be handled properly. --- ### Avoiding and finding errors --- #### Debugging --- 1. Get the program to compile. 2. Get the program to link. 3. Get the program to do what it is supposed to do. --- Think about debugging before you start writing code. --- * Add clear comments. * Use meaningful names. * Use a consistent layout (clang-format!). * Break code into small functions. * Avoid complicated sequences (nested loops, ifs, ...). * Use libraries instead of reinventing the wheel. --- #### Design by contract --- A contract consists of pre-conditions, post-conditions and invariants. --- ##### Pre-conditions --- A pre-condition is a requirement of a function upon its arguments. --- ```c++ int calculate_area(int length, int width) { if ((length < 0) || (width < 0)) { throw BadArea{}; } return length * width; } ``` What are the pre-conditions? Note: * The function takes two arguments. * Both arguments are of type int. * Neither of the arguments is allowed to be a negative value. --- Types are a form of pre-condition that is enforced by the compiler. --- Some pre-conditions we can enforce by writing code. --- Some pre-conditions cannot be expressed as code, but can be added as a comment. --- ##### Post-conditions --- A post-condition is a promise a function makes if and only if all pre-conditions are satisfied. --- ```c++ int calculate_area(int length, int width) { if ((length < 0) || (width < 0)) { throw BadArea{}; } return length * width; } ``` What are the post-conditions? Note: * There is one return value. * The type of the return value is an integer. * If both length and width are positive, the area will also be positive. --- ##### Writing contracts in code --- I don't want to add if statements with throw all over the place! 🙃 --- A helper function: expect() Note: * We have to implement expect() ourselves. * It is not part of the standard library. --- ```c++ [] int calculate_area(int length, int width) { // pre-condition expect([&]{ return (length >= 0) && (width >= 0); }, "length and width cannot be negative"); int result{length * width}; // post-condition expect([&]{ return result >= 0; }, "area is positive"); return result; } ``` If you give me a positive length and width, I promise you that the area will also be positive. Note: * Pre-conditions are the most important! * Post-condition are not often added as code. * We are using lambdas here, a short way of writing functions. * []{} declares a lambda. * Between [] we say which variables we want to be available inside the lambda body {}. * [&] means we want access to all variables. * We write the function body between {}. In this case it should return a boolean. --- ### C++26 will support contracts! 👍 But for now we are stuck with expect(). Note: * New syntax is accepted for C++26 that will allow you to write pre-conditions and post-conditions. --- ## Exercises
